Specifications

Transducer type
Condenser (back electret)

Operating principle
Pressure gradient

Polar pattern
Supercardioid

Frequency response
Close miking: 40 – 20,000 Hz
Distant miking (measured at 1 m) : 160 – 17,000 Hz

Open circuit voltage
3.2 mV/Pa (-49.9 dBV)* ±3 dB

Nominal impedance
approx. 650 Ω

Load impedance
> 3.5 kΩ

Max. SPL at 1 kHz
144 dB*

Equivalent SPL
37 dB SPL*

Power supply
Direct current 1.5 - 9 V

Max. power consumption
780 µA

Connector
Mini-XLR, 4-pin, female

Diameter
7.7 mm

Length microphone boom
158 mm

Weight
32 g

*measured with CV 18
